Plant Canopy Analyzer For Agricultural Production and Research

Cialan is a premier manufacturer and supplier of plant canopy analyzer in China, we provide forests canopy analyzer, portable canopy analyzer, leaf area index instrument and professional after-service.

0‐2700μmol ㎡/s

Measuring range

1 μmol ㎡/s

Resolution

＜10%

Relative difference

Product Details Characteristics Parameter Message

Quote Now Send Email

Product Details

Plant canopy analyzer can be used to investigate the light energy resources of the canopy, measure the light interception rate of the plant canopy, and study the relationship between crop growth and development, yield quality and light energy utilization. It is widely used in agriculture, forestry, botany research and canopy energy resource investigation.

CNP-1200 automatic type adopts non-destructive method to dynamically monitor plant growth. Utilizing near-infrared light reflectance spectroscopy technology and multi-channel spectral information scanning technology to meausre leaf area index(LAI). Mainly for high plant canopy like fruit trees.

CNP-1000 is used to measure and record photosynthetically active radiation (PAR) in the 400nm-700nm band, mainly for low plant canopy like grass.

Characteristics

The integrated design of display screen, operation keys, storage SD card and measuring probe makes it easy to operate, small in size and easy to carry. (CNP-1000)

SD card is used as the storage medium, with large storage capacity and convenient data management. (CNP-1000)

It has automatic sleep function. (CNP-1000)

The measurement methods of plant canopy analyzer are divided into automatic and manual. The automatic measurement interval is 1 minute, the number of automatic measurements is 99, and the manual measurement is manually collected according to actual needs. (CNP-1000)

High waterproof grade: all aluminum alloy, waterproof grade IP67. (CNP-1200)

Using visible/near-infrared light reflection spectrum technology and multi-channel spectral information scanning technology. (CNP-1200)

Many software analysis functions: it can analyze the vegetation index RVI,NDVI,nitrogen content in the crop leaf layer, nitrogen accumulation, LAI, leaf dry weight, etc. (CNP-1200)

The vegetation surface parameters, plant canopy information, plant nutrient information, soil nutrient information, environmental parameters, plant pests and diseases can be quickly determined. (CNP-1200)

Tags:

Portable plant canopy analyzer

Parameter

CNP-1000		CNP-1200
Measuring range	0‐2700μmol ㎡/s	With GPS positioning
Resolution	1μmol ㎡/s	With voice broadcast
Response time	10μs	With Cloud platform and mobile APP.
Qty of Sensors	25（standard equipped）	Channel:	2
Automatic acquisition interval	1-99 minutes	Acquisition area	0.23 ~ 0.38 ㎡
Automatic acquisition times	1-99 times	View angle	30 °
Data storage capacity	2GB (standard SD card)	Spectral bandwidth	<8nm FWHM
Probe length	50cm	Center Wavelength	680nm, 800nm
Meter length	75cm	Light Source	LED
Power supply	2*AA batteries	Power supply	8 ~ 12VDC
Working environment	0 ℃~60 ℃; 100% relative humidity	Working environment	0~ 60 ℃, 0 ~ 100% RH (no condensation of vapor
Stability	Change within one year ＜± 2%	Storage environment	-10 ~ 80℃, 0 ~ 40% RH
Gross weight	2kg	Gross weight	8kg
Packing size	25015050mm	Packing size	650350300mm
