15000rpm High Speed Micro Mini Centrifuge

Micro Centrifuge High Speed Mini type use centrifugal force to separate components in a mixture of liquid and solid particles or liquid and liquid.

15000rpm

Max Speed

5mL×18, 0.5mL×36, PCR8×4 etc.

Rotor Capacity

21380×g

Max RCF

Quote Now Send Email

Product Details Characteristics Parameter Message

Quote Now Send Email

Product Details

Micro Centrifuge High Speed Mini type use centrifugal force to separate components in a mixture of liquid and solid particles or liquid and liquid.

Characteristics

Special multi-flow air cooling design with patent ensures fast cooling of the rotor and low energy consumption.

Three-layer sealed rotor accidental leakage during centrifugal process allowing risk-free microbial contamination.

Temperature display appropriate for gentle handling of sensitive samples.High strength aluminum alloy rotor can be fully autoclaved for unlimited service life.

Four rotors are optional complete with 24 places 1.5/2.0mL tubes, bigger 5.0mL, smaller 0.2mL and 0.5mL tubes with adapters.

Tags:

Mini centrifuge

Parameter

Model	DM3024
Max. Speed	15000rpm(200-15000rpm), increment:10rpm
Max. RCF	21380×g, increment:10×g
Speed Accuracy	±20 rpm
Rotor Capacity	5mL×18, 5mL culture tubex12 0.2mL/0.5mL/1.5mL/ 2mL×24, 0.5mL×36, PCR8×4
Run Time	30sec-99min/Continuous
Motor	Brushless DC moto
Safety Devices	Dual door interlock, Over-speed detection, Automatic internal diagnosis
Power	Single-phase,AC220V-240V, 50Hz/60Hz, 5A, AC110V-120V, 50Hz/60Hz, 8A 200W
Acceleration /Braking time [Sec]	25s↑25s↓
Dimension [D×W×H]	280×364×266mm
Weight	12kg
Advanced Features	Speed/RCF switch; Short-time run function; sound-alert function
Noise Level	≦64dB
